A thought

BlueBMW

  • Hero Member
  • *****
  • Posts: 4346
Re: Turbo Grafx 16 / PC Engine / Express / GT Region Mod Chips for sale!
« Reply #136 on: March 29, 2014, 04:27:19 PM »
Are you thinking to make it even thinner?
[Sun 23:29] <Tatsujin> we have hard off, book off, house off, sports off, baby off, clothes off, jerk off, piss off etc

thesteve

  • Hero Member
  • *****
  • Posts: 2952
Re: Turbo Grafx 16 / PC Engine / Express / GT Region Mod Chips for sale!
« Reply #137 on: March 29, 2014, 04:46:53 PM »
Yes thinner
I cut the board to half thickness
Cut a hole for the chip and soldered it on with the bulk of the chip through the board for an example

BlueBMW

  • Hero Member
  • *****
  • Posts: 4346
Re: Turbo Grafx 16 / PC Engine / Express / GT Region Mod Chips for sale!
« Reply #138 on: March 29, 2014, 05:39:42 PM »
Pretty slim.... Hehe

[Sun 23:29] <Tatsujin> we have hard off, book off, house off, sports off, baby off, clothes off, jerk off, piss off etc

turbokon

  • Hero Member
  • *****
  • Posts: 2181
Turbo Grafx 16 / PC Engine / Express / GT Region Mod Chips for sale!
« Reply #139 on: March 31, 2014, 01:22:45 AM »
Whoa thesteve, that's seem like a lot of work:)

I know there's no room for the bottom shield with the current configuration in the TE/GT.  Maybe there is a better spot for the region chip like opposite of battery bay area.
